New Wheel Loaders

Hyundai HL760-9

  • Make
    Hyundai
  • Model
    HL760-9
  • Operating Weight
    17,900 kg
  • Engine details
    Cummins QSB6.7
  • Engine power
  • capacity
    3.3 m³ (heaped)
  • hopper capacity
    3.3 m³ (heaped)
  • working width
  • other models
    HL760XTD-9

Build a better future with the Hyundai Construction Equipment HL760-9 Wheel Loader. Innovative hydraulic system technology makes the HL760-9 wheel loader fast, smooth and easy to control. All dash 9 series wheel loaders are designed for maximum performance to keep the operator working productively.

request a quotedownload brochure
New Wheel Loaders

Hyundai HL760-9

Build a better future with the Hyundai Construction Equipment HL760-9 Wheel Loader.

Engine Technology
Proven, reliable, fuel-efficient, low noise, Tier-III certified Cummins QSB6.7 engine. Electronically controlled for optimum fuel to air ratio / Clean and efficient combustion HPCR (High-Pressure Common Rail) fuel system / self-diagnostic system. 3 engine modes, P (Power), S (Standard), E (Econo) for full power or reduced fuel consumption according to operator preference.

ZF Full Automatic Transmission
The Hyundai HL760-9 features 4 automatic modes (Manual / Light / Normal / Heavy) for various applications. Protection transmission at low temperature (with Automatic warm-up system). Self-diagnostic & history of alarms. Smooth gear shifting by applying proportional controlling modulation valve / Self adjusting Clutch gap. Kick-down button & Forward-Neutral-Reverse switch for increased comfort.

Axles
Front and rear axle equipped with Limited slip differential for maximum traction on different ground conditions Self-adjusting brakes, mounted in wheel hubs.

High Durability
Features the Hyundai HL760-9 “Load sensing – Flow sharing” hydraulic system with variable displacement pump. Improved cooling system with high resistance to thermal shocks and vibrations. Steering cylinder lug & bucket link designed with reinforced and stressless cast steel.

Improved Convenience
The Hyundai HL760-9 features increased cooling & heating capacity with fully automatic temperature control. Tilting & telescopic steering column and large adjustable wrist rest to meet all operator’s preferences Various storage spaces in the cab / Radio & MP3 player with USB-input Stair with large aluminium steps for easy and safe access to the cabin.

Advanced Colour LCD-display
New color LCD-display with easy to read digital gauges for hydraulic oil temperature, water temperature and fuel level. Monitoring system with boom & bucket position settings and payload system to increase work efficiency and overload prevention. Through the LCD-display, the condition of engine, transmission and other electric devices can be checked with the blink of an eye. Automatic activated rearview camera for easier and safer work. Hi-mate, Hyundai’s newly developed remote management system, using GPS-satellite technology, provides our customers with the highest level of service and product support.

Easy Serviceability
The Hyundai HL760-9 features a reversible, swing-out, cooling fan for easy service and improved cooler maintenance. Ground level access to critical service points, filters, and sight gauges for easy maintenance. Long-life hydraulic filter and oil for reduced operating costs.
